Description

K1GPS tracker is a model which is suitable for motorcycle or tuktuk. Power input range is 8-92V with an industrial design plus super power saving technology to save tuktuk or motorcycle battery life.

Internal GPS/GSM antennas, IP66 waterproof, digital input, and 1 output. K1 GPS tracker uses EU standard GPS Tracking platform supporting multiple languages which is simple and practical, this enables the customers to integrate into their own application efficiently through open API technology.

​Specifications

• Content Specs.
• Built-in battery(Optional) 3.7V /55mAh Li-ion battery
• Input Voltage 35mA @DC 9V-40V, Sleep Current:0.8mA
• Dimension 8cm x 3.3cm x 1.4cm
• Weight 30g
• GSM: 850/900/1800/1900 MHz
• Network& Band
• (Optional)
• GPS sensitivity -159dBm
• GPS accuracy <10M
• Cold start 45s
• Time To First Fix Warm start 35s
• Hot start 1s
• Storage Temp. -40°C to +85°C
• Operation Temp. -20°C to +55°C
• Humidity 5%–95% non-condensing

FUNCTION

◇ GPS satellite & LBS base station dual model positioning
◇ Vibration alarm (G-sensor sensitivity is adjustable from 1 to 5 grade)
◇ Low current consumption sleep mode
◇ ACC detection(Digit input1: 9-40V)
◇ Remote control cut-off/on engine (petrol / electricity)
◇ Power cut off alarm
◇ SOS Alarm
◇ VOICE MONITORING
◇ GEO-fence
◇ 128M data storage while no GSM
